Real-time Device Monitoring
Live health, uptime and telemetry streamed from every connected device.
Madhya Pradesh Data Platform · Archive & Documentation
Game API Connect Device Admin
Unified device management and API orchestration for the Madhya Pradesh data ecosystem.
POST /api/v1/devices/register
{
"region": "madhya-pradesh",
"protocol": "grpc",
"role": "edge-node"
}
// 01
System Architecture
A layered platform that ingests, secures and orchestrates device traffic across the state data network — designed for reliability at scale.
-
API Gateway Layer
Single entry point handling routing, rate limiting and request validation for every connected client.
-
Device Management Module
Registration, health tracking and remote configuration of edge devices across districts.
-
Data Processing Pipeline
Stream ingestion, normalization and enrichment before persistence and analytics.
-
Authentication & Authorization
Token-based identity with fine-grained role and scope checks on every request.
-
Database & Storage Layer
Durable relational store plus object storage for telemetry, logs and archived payloads.
API Gateway Layer
↓
Device Management
Auth & AuthZ
↓
Data Processing Pipeline
↓
Database & Storage Layer
// gateway/routes.ts
router.use("/devices", authGuard("device:admin"))
router.post("/devices", registerDevice)
router.get("/devices/:id/health", deviceHealth)
// 02
Core Features
Capabilities that keep the device fleet observable, secure and fast.
Multi-Protocol Support
Native handling for HTTP, WebSocket and gRPC transports on one gateway.
Scalable Data Pipeline
Horizontally scalable ingestion that keeps pace with growing device load.
Role-based Access Control
Granular scopes and roles enforced on every device and API operation.
Distributed Caching Layer
Low-latency cache in front of storage to serve hot device data instantly.
Analytics & Dashboards
Aggregated metrics and visual dashboards for operators and stakeholders.
// 03
Live System & Screenshots
Representative views of the admin console. Interface mockups shown for documentation purposes.
// 04
Tech Stack
Technologies powering the platform end to end.
Backend
- Node.js
- TypeScript
- gRPC
- Express
- WebSocket
Frontend
- HTML5
- CSS3
- JavaScript
- Chart.js
Data
- PostgreSQL
- Redis
- Kafka
- Object Storage
Infrastructure
- Docker
- Kubernetes
- NGINX
- Prometheus
